ABB Sensycon Harmann & Braun

Valve Positioners (TZID, TZID-C & Bailey AV Series)
(List of Standard US TZIDC Positioners)
Overview of ABB (Sensycon) Valve Positioners
MODEL
 NAME
 MODEL CODE

DESCRIPTION

Data Sheet

Manuals

TZID (V18341) Intelligent Valve Positioner


EPD300

PositionMaster EDP300
Electro-Pneumatic Positioner



TZIDC (V18345) Intelligent Positioners


V18345
TZIDC

Intelligent Positioner with HART

V18346
TZID-C110

TZID-C with interface to Profibus


V18347
TZID-C120

TZID-C with interface to FOUNDATION Fieldbus™



TZIDC-200 with Explosion Proof Enclosure


V18348
TZID-C200

TZID-C200 for for hazardous locations


V18349
TZID-C210

TZID-C200 with interface to Profibus


V18350
TZID-C220

TZID-C200 with interface to FOUNDATION Fieldbus™



TZID (V18341) Intelligent Valve Positioner


TZID valve positioner V18341
TZID

Intelligent Positioner - No Longer Manufactured

 See Recommendations


TZID valve positioner V18342
TZID Exd

Explosion proof  TZID. This has been replaced by the TZIDC-200



TZIM (V18333) Valve Positioner


TZIM valve positioner V18333
TZIM

Simple Electro-pneumatic positioner for low cost applications
NOTE: THIS UNIT IS NO LONGER BEING SOLD



Bailey Controls AP & AC Positioners




Bailey
Controls
AP & AC
Units

These units are obsolete and parts are no longer available but can be replaced by the AV or TZID positioners. Please see the Conversion Guide ---->



ABB-Bailey Valve Positioners



Bailey
Controls
AV1

Type AV1 positioner are pneumatic positioners that use a pneumatic input to control the pneumatic output.

Bailey
Controls
AV2

Type AV2 and AV3 positioners are electro-pneumatic, with Type AV2 and AV3 using an I/ P (current-to-pneumatic) converter to accept a four to 20-milliampere input signal and convert it to a pneumatic output. The Type AV2 fails open/closed

Bailey
Controls
AV3

Type AV3 fails in place on loss of current input signal.

Mounting Options for  ABB Valve Positioners



US Rising Stem Valve

Mounting Instructions for TZID-C
 Kit #614C190U15


Masoneilan Camflex II Rotary

 Mounting Instructions for TZID-C Smart Positioner on a  Masoneilan Camfles II Rotary Valve



Fisher Type 657/667
Copes-Vulcan Type 700

Mounting instructions TZID-C & TZID-C200 for Linear Actuator Types: Copes-Vulcan Type 700, Fisher Type 657/667



Fisher Type 585

Mounting instructions TZID-C & TZID-C200for Linear Actuator Type: Fisher Type 585C
